Single axle trailer fabricators
Ultimate Plant Trailers offer a wide range of single axle trailers, perfect for transporting plant machinery and attachments weighing up to seven tonnes, subject to truck and trailer capabilities.
Take a look at our standard machinery trailer features below or contact us to discuss what we can do for you.
Standard single axle trailer features
| Chassis:- | 8mm Laser cut single piece webplate with 16mm fully welded bottom strap with 17mm camber over the span of the trailer |
| Coaming:- | 10mm lasercut flush mount with rear mounted tie bars and recessed lighting and reflectors. |
| Drawbar:- | Fabricated with a 12mm top and bottom strap fully welded and to the specific height of your trucks hitch |
| Deck:- | 5mm Australian Checker plate steel with 10mm in deck bissalloy chain points |
| Axles:- | Drum brake to suit 17.5, 19.5 22.5″ Rims, Fuwa K Hitch or BPW |
| Suspension:- | 9 Leaf Spring or Airbag |
| Rims and Tyres:- | Alloy, Steel and Chrome Rims Available fitted with Triangle Tyres |
| Ramps:- | Heavy Duty Customizable Length, Hydraulic or spring assisted. |
| Front leg:- | Hydraulic or 2 speed manual operation available in single or dual legs. |
| Finish:- | Class 2 fully sand blasted trailer and components followed by Epoxy primer and Custom 2 Pack Paint |
Optional extras provided by our single axle trailer builders
- Full hydraulic ramps and legs
- Air bag suspension
- Storage solutions
- Over-size sign and flag kit
- Extra-wide, extra-long ramps
- Container pins
- Diesel fuel systems
- Alloy ramp slides
- In-deck well
- Auger racks.
If you don’t see what you’re after in our single axle trailers range, you can also take a look at our tri axle and tandem axle trailers, or give us a call to discuss custom trailer fabrications.
